The XT M3 is a powerful yet compact microATX chassis ready for any gaming PC configuration. Plenty of fan positions, including triple 120 fan positions in the bottom and dedicated radiator space in the top, provide plenty of cooling options within its sleek and clean appearance.

With its innovative layout and strikingly clean design, the XT M3 is a microATX powerhouse ready for any cooling challenge.

• Supports a total of nine 120 fans for powerful cooling within this compact chassis.

• Dedicated 360 radiator space in the top of the chassis.

• Triple fan locations in the bottom for direct GPU cooling

  Organized by Design

  • Spacious cable routing area for clean and efficient management.
  • Fully compatible with Rear-Connect mainboards for streamlined builds.













  Fan Positions

  • 3x 120 mm top fans.

  • 2x 120 mm front fans.

  • 1x 120 mm rear fan.

  • 3x 120 mm bottom fans.




  Radiator Positions

  • 1x 360 top radiator up to 410 x 122 x 60 mm

  Storage

  • SSD Storage Bracket
    Supports 2x 2.5″ SSD drives.
  • HDD Storage Bracket
    Supports 1x 3.5” HDD drive.



  Specifications

  General

  Model No.

  PH-XT325M_WT01

  UPC Code

  886523303916

  Case Dimensions

  460 x 235 x 370 mm | 18.1 x 9.3 x 14.6 in

  From Factor

  Compact microATX tower

  Mainboard Support

  Micro-ATX | Mini-ITX

  Materials

  Steel chassis | Tempered glass window | ABS plastic

  Color

  White

  Expansion Slots

  4

  Vertical GPU Support

  No

  Internal 2.5″ Positions

  2

  + 1x 3.5″ HDD

  Internal 3.5″ Positions

  1

  + 2x 2.5″ SSD

  Front I/O

  1x USB 3.0
  1x USB-C 3.2 Gen2x2
  1x Microphone | Headphone combo
  Power button

  Fans 120 | 140

  Total Fans

  9 | –

  Top

  3 | –

  Front

  2 | –

  Side

  – | –

  Rear

  1 | –

  Bottom

  3 | –

  Radiator 120 | 140

  Top

  Max. 360 | –

  Front

  – | –

  Rear

  – | –

  Bottom

  – | –

  Clearance

  CPU Cooler

  Height

  175 mm | 6.88 in

  GPU

  Length

  430 mm | 15.94 in
  Without front fans installed

  GPU

  Width

  175 mm | 6.88 in

  Power Supply

  150 mm | 5.90 in

  Top 360 Radiator

  Length x Width x Height

  410 x 122 x 60 mm | 16.14 x 4.80 x 2.36 in

  Extra

  Net Weight

  5.57 kg | 12.28 lbs

  Gross Weight

  6.90 kg | 15.21 lbs







  Scope of Delivery

  1x XT M3 chassis
  1x SSD bracket Pre-installed
  1x HDD bracket Pre-installed

  Accessory Box

  9x Zip ties
  1x Stand-off removal tool
  1x GPU support

  Screws

  17x Mainboard | SSD screws
  5x Power supply screws
  4x HDD screws
  1x Mainboard stand-off
