j5create JCH471 USB Type-C Hub Adapter with Gigabit Ethernet and 3X USB 3.0 Ports

• • Gigabit Ethernet and 3-Port HUB over a USB Type-C connection
• • 5 Gbps transfer rate
• • Aluminum housing
• • Compatible with Windows/Mac/Linux/Chrome OS

The JCH471 USB Type-C Gigabit Ethernet & HUB Multi Adapter provides extra connectivity for your computer with 5 Gbps transfer speed. Our pocket-sized multi-adapters allow you to add additional USB computer accessories and Gigabit LAN through your USB Type-C port.

This Gigabit Ethernet adapter allows you to add networking capabilities to a computer that does not have a Wireless LAN connection. It has an RJ-45 connector that supports 10/100/1000 Mbps Ethernet performance, and it is perfect for MacBook Air, Chromebook, and other laptop and desktop computers with a USB-C port.

Fast and portable, this unique adapter gives you Ethernet and USB connections all in one.

Interface
Host Interface	USB-C™ Male connector
Ethernet Port	RJ-45 Female connector (Gigabit Ethernet)
USB™ Port	USB™ 3.0 Female connector x 3 ports
LED	Activity and Link LED indicators
Power Jack	DC 5V (3.5 mm OD, 1.35 mm ID)
Power
Power Mode	Bus-powered or Self-powered If you are using a high-powered USB™ device, please connect your multi adapter to an AC/DC power adapter to ensure maximum performance.
Functions
Ethernet	Transfer Rate: 1000 Mbps (Half Duplex) / 1000 Mbps (Full Duplex) IEEE: IEEE 802.3az, IEEE 802.3, 802.3u, and 802.3ab, IEEE 802.3x Modes: • Supports Wake on LAN function, suspend mode and remote wakeup via link-change, Magic Packet™ or Microsoft® wake-up frame • Supports IEEE 802.1Q VLAN tagging and 2 VLAN ID filtering • Supports Jumbo Frame • Supports Checksum Offload (IPv4, IPv6, TCP, UDP) and TCP Large Send Offload
Physical Specifications
Dimensions	Main body: 43.75 (W) x 90.6 (H) x 18.6 (D) mm Cable length: 14.5 cm
Weight	Approximately 58.5 g (including cable)



System Requirements

• Windows® 10
• macOS® X v10.8 or later
• Linux® Kernel 3.x / 2.6.x
• Available USB-C™ port
• Driver not required for Chrome OS 3.8 and Linux 3.1x and up

• Note: Driver is required for Windows 10
